Okwanjula
SAE hydraulic pipe flanges are high-ebitundu by’okuyunga eby’okukola ebikoleddwa okusobola okutambuza amazzi aganywevu, agakulukuta-Okutambuza amazzi mu nkola z’amazzi ezisaba. Flanges zino ezikolebwa ku mutindo gwa SAE J518 ne ISO 6162, zikakasa omulimu ogwesigika mu kussa mu makolero ag’enjawulo-okunyigirizibwa mu makolero ag’enjawulo.
Ebikwata ku nsonga .
|
Ekitundu nnamba. |
Flange Size . |
Hose bore . |
Ebipimo . |
|||||
|
DN . |
OKWANGUWA |
A |
C |
D |
H |
L |
||
|
87641-08-08 |
1/2" |
12 |
08 |
58.9 |
31.7 |
24 |
24 |
7.75 |
|
87641-08-12 |
1/2" |
20 |
12 |
74.9 |
31.7 |
24 |
27.5 |
7.75 |
|
87641-12-10 |
3/4" |
16 |
10 |
72.5 |
41.3 |
32 |
28.2 |
8.76 |
|
87641-12-12 |
3/4" |
20 |
12 |
79.2 |
41.3 |
32 |
31.8 |
8.76 |
|
87641-16-16 |
1" |
25 |
16 |
90.2 |
47.6 |
38 |
34.7 |
9.53 |
|
87641-20-20 |
1.1/4" |
32 |
20 |
103.8 |
54 |
44 |
41.5 |
10.29 |
|
87641-24-20 |
1.1/2" |
32 |
20 |
105.8 |
63.5 |
51 |
45.1 |
12.57 |
|
87641-24-24 |
1.1/2" |
40 |
24 |
116.2 |
63.5 |
51 |
45.5 |
12.57 |
|
87641-32-24 |
2" |
40 |
24 |
125.4 |
79.4 |
67 |
54.7 |
12.57 |
|
87641-32-32 |
2" |
50 |
32 |
135.7 |
79.4 |
67 |
52.7 |
12.57 |
Parameters/Technical Data .
|
Yiiye |
Zhejiang, China . |
Olunaku lw'okutuusa . |
Enteeseganya . |
|
Okuweebwa satifikeeti . |
GB/T19001-2016 IDT ISO9001:2015 |
Okupakinga . |
Omutindo gw’okutunda ebweru w’eggwanga . |
|
Ekikozesebwa |
Ekyuma kya kaboni . |
Waranti . |
Omwaka 1 . |
|
Ekisanja ky’okusasula . |
TT . |
MOQ . |
2000 |
|
Kakwakkulizo |
Pya |
Erangi |
Zinki enjeru, langi zinki . |
Ebikwata ku Kampuni .
Ebirungi .
Omutindo gwa puleesa ogutaliiko kye gufaanana .
Engineered okugumira pressure ya psi 10,000 psi .
30% higher pressure rating okusinga standard SAE ebyetaago .
Ekuuma obutuukirivu bwa seal wansi w’embeera y’okuvuga obugaali eya puleesa ey’amaanyi .
Precision Manufacturing Okusukkuluma .
CNC ekoleddwa mu kyuma okutuuka ku ±0.005" okugumiikiriza okusobola okutuuka obulungi
Okuzimba okujingirira (si kusuulibwa) olw’amaanyi agasukkulumye .
Micro-ebitundu ebisiba ebiwedde (RA < 0.4μm) .
Omutindo gw'ebintu ogw'oku ntikko .
Ennyonyi-Ekyuma kya kaboni eky'ekika nga kiziyiza okukoowa okunywezeddwa .
316L Ekyuma ekitali kizimbulukuse eky'okulonda nga kiziyiza okukulukuta kwa 5x .
Full material okulondoola n'okugezesebwa kw'ekyuma .
Okuvuba-Okukakasa okukakasa .
Tekinologiya wa quad-SsealTM (primary, secondary, ne dual backup seals, secondary ne dual backup seals)
Pre-Essigiddwa waggulu-Enkola FKM O-Empeta (-65 Degree F okutuuka ku +400 diguli F)
Puleesa 100% egezeseddwa okutuuka ku 1.5x working pressure .
amakolero-okukulembera okuwangaala .
Obulamu bw'obuweereza obuwanvu 50% okusinga ku mutindo gw'amakolero .
Ebintu eby’enjawulo ebikalubye okukozesebwa mu kukozesa amazzi agawunya .
Impact-Enkola egumikiriza ku mbeera za waggulu-Okukankana .
Global Compliance & Certification .
Ekakasibwa SAE J518, ISO 6162, ne ASME B16.5.
PED 2014/68/EU .
ABS ne DNV-Okukkiriza kw'ennyanja GL Kuliwo .
Ebirungi by'okuteeka .
Laser-obubonero obulaga okuzuula okusobola okwanguyirwa okulaga .
pre-okukuŋŋaanyizibwa n'obulagirizi obulaga .
40% Okuteekebwa amangu okusinga flanges eza bulijjo .
Obusobozi bw’okulongoosa .
Esangibwa mu sayizi okuva ku 1/4" okutuuka ku 6".
Ebikozesebwa eby’enjawulo omuli Monel, Hastelloy, ne Titanium .
Ensengeka z'omwalo eza bulijjo n'okugereka puleesa .
Okukakasa omutindo omukakali .
100% dimensional verification ne CMM .
Okugezesa obulungi bw’ebintu mu ngeri ya ultrasonic .
Batch traceability nga eriko ennamba ez’enjawulo .
Obuyambi obw'ekikugu obutaliiko kye bufaanana .
Ttiimu ya Engineering ey'okusaba eyeetongodde .
Okwekenenya enkola y'amazzi ku bwereere .
ON-Okutendekebwa mu kussa mu kifo kuliwo .
FAQ .
Q: SAE Flanges zo zituukana ki?
A: Flanges zaffe zisisinkana:
SAE J518 (Ekikoodi 61 & 62)
ISO 6162 (omuddiring’anwa 1 & 2)
DIN 20066 .
ASME B16.5 (ng’osaba)
Q: Puleesa ki eziriko?
A: Ebika bya puleesa eby’omutindo:
3000 PSI (Ebbaala 207) Omusomo ogw'omutindo .
6000 psi (ebbaala 414) obuwanvu -omulongooti gwa puleesa .
Dizayini ez’enjawulo ezituuka ku 15,000 psi (ebbaala 1034)
Q: Bikozesebwa ki by’owaayo?
A: Ebikozesebwa eby’omutindo:
AISI 4130 Ekyuma kya kaboni .
304/316 Ekyuma ekitali kizimbulukuse .
Alloys ez’enjawulo:
Duplex 2205 .
Inconel 625 .
Titanium Ekibiina eky’okutaano .
Q: Nkola ntya ku sayizi ya flankisi entuufu?
A: Ebisumuluzo Okulonda Ebipimo:
Payipu ey’omuwendo (NPS) .
Enkola y’okukola puleesa .
Ebyetaago by’okukulukuta (GPM) .
Ebbugumu eriyita mu .
Bayinginiya baffe bawa okwebuuza okw'obwereere
Q: Biki eby’okusiba ebiriwo?
A: Ensengeka z’okusiba:
O-Empeta ya ffeesi (ORFs) - omutindo .
RTJ (Ekiyungo eky’ekika ky’empeta) .
Feesi epapajjo nga eriko gaasikiti y’ebiwundu eby’ekika kya spiral .
Ekyuma-Okugenda-Ekisiba ekyuma ku pulogulaamu za waggulu-.
Q: Flanges zo zikyusibwakyusibwa ne brand endala?
A: Yee, flanges zaffe:
Kuuma okugoberera ebipimo bya SAE/ISO mu bujjuvu .
zikyusibwakyusibwa 100% nga zirina dizayini eza bulijjo .
Muteekemu okugumiikiriza-ebitundu ebifugibwa okugatta .
Q: Obudde bwo obw’okukulembera ku biragiro bya custom?
A: Ebiseera by’okufulumya:
Ebintu ebikozesebwa mu kukola emirimu: Okusindika essaawa 24
Standard Custom: Ennaku z'omulimu 5-7
Alloys ezenjawulo: wiiki 2-3
Ebifo eby'amangu eby'okufulumya .
Q: Owaayo obuyambi bw’okussaako?
A: Enteekateeka y’okuwagira mu bujjuvu:
Digital Torque Calculators .
3D Okuteeka ebifaananyi ebirina obulamu .
Ebiragiro ebikwata ku kuteeka ennimiro .
ON-Omukugu mu by'ekifo (Optional)
Q: Certification ki z’okuuma?
A: Ebisaanyizo ebiriwo kati:
ISO 9001:2015 (QMS)
API Q1 (amafuta ne ggaasi) .
PED 2014/68/EU Ekika kya IV .
DNV-GL Marine .
Q: Okuddaabiriza ki ekiragiddwa?
A: Okuddaabiriza okuziyiza:
Okukakasa torque buli mwaka .
Okukebera Envumbo ya Biennial .
Okugezesebwa kwa Ultrasonic okw'emyaka 5 .
Okukyusa oluvannyuma lw'okuzimbulukuka 50,000 .
